» 65-581

Discontinued – Suggested Replacement: 65-581R1
65-581 2X2 LED BACKLIT FLAT PANEL

65-581

2X2 LED BACKLIT FLAT PANEL

LED Backlit Flat Panel; 40 Watt; 2 ft. x 2 ft.; Selectable CCT; 100-347 Volt


SATCO|NUVO's LED-backlit panel with ColorQuick technology is a versatile lighting fixture. Through advanced manufacturing, even light distribution is achieved at an even greater cost savings. Satco's ColorQuick and PowerQuick technologies allow for numerous configurations of light in one fixture making it extremely versatile to suit various application needs. From office buildings and schools to doctors offices and hospitals, this panel produces extremely efficient and uniform light with a long maintenance-free life to offer premium value for all your lighting needs.
  • 0-10 volt dimming
  • 80 CRI
  • Damp location rated
  • 50,000 average rated hours of use
  • Suspension kit available
  • Surface mount frame kit available
  • Surface mount frame kit available
  • Drop ceiling installation (T-bar grid)
Lights

65-581

2X2 LED BACKLIT FLAT PANEL

LED Backlit Flat Panel; 40 Watt; 2 ft. x 2 ft.; Selectable CCT; 100-347 Volt

SATCO|NUVO's LED-backlit panel with ColorQuick technology is a versatile lighting fixture. Through advanced manufacturing, even light distribution is achieved at an even greater cost savings. Satco's ColorQuick and PowerQuick technologies allow for numerous configurations of light in one fixture making it extremely versatile to suit various application needs. From office buildings and schools to doctors offices and hospitals, this panel produces extremely efficient and uniform light with a long maintenance-free life to offer premium value for all your lighting needs.
  • 0-10 volt dimming
  • 80 CRI
  • Damp location rated
  • 50,000 average rated hours of use
  • Suspension kit available
  • Surface mount frame kit available
  • Surface mount frame kit available
  • Drop ceiling installation (T-bar grid)

Specifications

General
StatusDiscontinued
Substitute65-581R1
Fixture TypeBacklit Flat Panel
FinishWhite
Wattage40W
Lumen Output4400L-4600L
CCT (Kelvin)3500K/4000K/5000K
IP RatingIP20
Indoor or Outdoor FixtureIndoor
Panel Size2x2
Specifications
TechnologyLED
Wattage40W
Lumen Output4400L-4600L
CCT (Kelvin)3500K/4000K/5000K
Color TemperatureWarm to Cool White
CRI80+
Voltage100V-347V
Beam Angle120
Rated Hours50000
Operating Temperature-17C (+1.4F) to +45C (+113F)
DimmableYes-Dimmable
Dimming Note0-10V Dimming Only
Photocell or SensorNo Photocell
Lens MaterialPoly methyl methacrylate (PMMA)
Surge ProtectionBuilt-in surge protection - 2KV
Weight (lb.)4.85
IP RatingIP20
MaterialAluminum / Steel
Dimensions
Height (in.)1.5
Width (in.)23.75
Length (in.)23.75
Compliance
Safety ListingcETLus - Listed
Location RatingDamp
UL ApplicationLED Panel Luminaire
Energy StarNo
DLC ApprovedYes
DLC IDPLGZ8OJ3A5EO
NSF ApprovedYes
Air Tight RatedNo
IC RatedYes
CA T20 / T24 RationaleT20 Exempt - Fixtures Not Regulated
California Prop 65
RoHS CompliantYes
FCC CompliantYes
Flicker FreeYes
SDS SheetLED Fixture
Additional Information
Warranty5 Year Limited - Fixtures
Packaging
Each UPC045923659522
Each Quantity1
Each Length (in.)25.00
Each Width (in.)2.56
Each Height (in.)25.20
Each Weight (lb.)6.50
Each Cube (CuFt.)0.9333
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923659529
Case Quantity1
Case Length (in.)25.00
Case Width (in.)2.56
Case Height (in.)25.20
Case Weight (lb.)6.50
Case Cube (CuFt.)0.9333
×

Dimmer Compatibility

Type Brand Model Number Website
Dimmer Eaton DF10P Visit
Dimmer Eaton SF10P Visit
Dimmer Legrand ADPD4FBL3P2W4 Visit
Dimmer Leviton DS710-10Z Visit
Dimmer Leviton IP710-LFZ Visit
Dimmer Lutron DVSCSTV Visit
Dimmer Lutron DVSTV Visit
Dimmer Lutron DVTV + PP347H 347V ONLY Visit
Dimmer Lutron MS-Z101-V Visit
Dimmer Lutron NTSTV-TV Visit
×
×
×

Precautions

No precautions available at this time.

×
California Prop 65 Warnings
Material Warning
Lead WARNING: This product can expose you to chemicals including Lead and lead compounds, which are known to the State of California to cause cancer or birth defects or other reproductive harm.
